ASUS ROG STRIX B850-A GAMING WIFI

ASUS ComponentsWhats New

ROG STRIX B850-A GAMING WIFI motherboard socket AMD AM5 (AMD B850, ATX, DDR5 memory, PCIe 5.0, WiFi 7, 3x PCIe 4.0 M.2, Aura Sync)

Availability:

Out of stock

R6,470.82

Out of stock

Elevate your build with the ROG Strix B850-A Gaming WiFi. Featuring a sleek white PCB and support for AMD Ryzen™ 9000 Series processors, this motherboard delivers the power and connectivity needed for advanced AI applications. With DDR5 support, full PCIe 5.0 capabilities, USB 20Gbps port, and WiFi 7, it’s the ultimate blend of style and performance.

ASUS AI INTELLIGENCE

ASUS AI ADVISOR
Using AI technology to understand natural-language questions or scenario descriptions, ASUS AI Advisor allows users to explore the functionality and advanced features of ASUS motherboards in a simple and straightforward way.
*Availability of ASUS AI Advisor may vary by region.
**AI Advisor functions may vary by platform.

AI NETWORKING II
AI Networking II combines intelligent technologies to continuously optimize network performance, provide trustworthy and seamless connectivity, and unleash the full speed of WiFi 7*.
*Features may vary by model.

OVERCLOCKING

PBO ENHANCEMENT
AMD Precision Boost Overdrive (PBO) pushes the CPU current and voltage budget to opportunistically increase performance. By aggressively tuning the PBO parameters, AMD’s algorithm can leverage the motherboard’s robust power solution to ramp up performance even higher.

MEMORY

DDR5 DOMINATION
The Strix B850-A is primed and ready for enthusiast-grade kits courtesy of vast AMD Extended Profiles for Overclocking (EXPO) support.

AEMP
ASUS Enhanced Memory Profile (AEMP) is an exclusive firmware feature for PMIC-restricted memory modules.

ROG STRIX ULTIMATE POWER DESIGN
14(80A)+2(80A)+2(80A) Power Stages

PLAY IN STYLE

UNDENIABLY ROG STRIX
The ROG Strix B850-A stands out with its striking white PCB, offering a fresh and modern aesthetic that seamlessly complements almost any system build. The matching metallic heatsinks enhance its clean, crisp look, while subtle RGB lighting on the I/O shroud allows you to either maintain a sleek, understated appearance or showcase a bold, luminous design.

OUTSHINE THE COMPETITION
ROG Strix motherboards feature ASUS Aura technology, enabling full lighting control and a variety of presets for both onboard RGB LEDs and third-party accessories. Effects can be easily synced across compatible ROG graphics cards, monitors, keyboards, and mice to give your setup a unified look.

BUILD FOR THE MOST ADVANCED PC FOR GAMING AND CREATING
When only the fastest will do, a Strix B850 motherboard delivers. With USB 20Gbps onboard along with robust overclocking¹ capabilities, featuring faster dual-channel DDR5 memory support, AMD EXPO™ technology and PCIe® 5.0 support for both graphics and NVMe, you can play the most demanding games and deliver your biggest projects with the revolutionary performance of an AMD 800-series motherboard and AMD Ryzen™ 9000, 8000, and 7000 Series processors.

Dare to Be Green
We at the Republic of Gamers are on a mission to create a sustainable future where all gamers can flourish on the planet we call home.

Every step counts, and as part of ROG’s commitment to creating a more sustainable future, ROG has begun to utilize post-consumer recycled (PCR) plastic and paper materials certified by the Forest Stewardship Council (FSC™) in the packaging of motherboard.

Weight & dimensions
Width 305 mm
Depth 244 mm
Memory
Maximum internal memory 192 GB
Supported memory types DDR5-SDRAM
Memory channels Dual-channel
Memory slots type DIMM
Unbuffered memory Yes
Number of memory slots 4
Supported memory clock speed (max) 8000 MHz
ECC сompatibility ECC & Non-ECC
Processor
Compatible processor series AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Processor socket Socket AM5
Supported processor sockets Socket AM5
Processor manufacturer AMD
Rear panel I/O ports
USB 2.0 ports quantity 2
Ethernet LAN (RJ-45) ports 1
Headphone outputs 1
S/PDIF out port Yes
VGA (D-Sub) ports quantity 0
WiFi-AP antenna jack 2
DVI-D ports quantity 0
Digital audio optical out 1
HDMI ports quantity 1
DisplayPorts quantity 1
HDMI version 2.1
DisplayPort version 1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 1
USB 3.2 Gen 2×2 Type-C ports quantity 1
Line-in Yes
Internal I/O
Number of SATA connectors 0
USB 2.0 connectors 2
CPU fan connector Yes
ATX Power connector (24-pin) Yes
Number of chassis fan connectors 4
Front panel audio connector Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors 1
Number of SATA II connectors 0
Number of SATA III connectors 2
EPS power connector (8-pin) Yes
Thunderbolt headers 1
USB 3.2 Gen 2 (3.1 Gen 2) connectors 1
Front panel connector Yes
RGB LED pin header Yes
Number of CPU fan connectors 2
Number of RGB LED pin headers 3
Number of water pump connectors 1
Number of EPS power connectors (8-pin) 2
Number of temperature sensor headers 1
Network
Ethernet interface type 2.5 Gigabit Ethernet
Bluetooth Yes
Bluetooth version 5.4
Wi-Fi standards Wi-Fi 7 (802.11be)
Ethernet LAN Yes
Wi-Fi Yes
Top Wi-Fi standard Wi-Fi 7 (802.11be)
Expansion slots
Number of M.2 (M) slots 4
PCI Express x16 (Gen 4.x) slots 1
PCI Express x16 (Gen 5.x) slots 1
1st M.2 largest key size 2280
1st M.2 highest PCI Express generation 5.0
2nd M.2 largest key size 22110
2nd M.2 highest PCI Express generation 4.0
3rd M.2 largest key size 2280
3rd M.2 highest PCI Express generation 4.0
4th M.2 largest key size 2280
4th M.2 highest PCI Express generation 4.0
Packaging content
Cables included SATA
Antenna included Yes
BIOS
BIOS type UEFI AMI
BIOS memory size 256 Mbit
Clear CMOS button Yes
Other features
Weight 2.04 kg
Quick installation guide Yes
mSATA ports quantity 0
Graphics
Parallel processing technology support Not supported
Maximum resolution 7680 x 4320 pixels
On-board graphics card No
Features
Motherboard form factor ATX
Motherboard chipset AMD B850
Audio output channels 7.1 channels
Motherboard chipset family AMD
Component for PC
Windows operating systems supported Windows 11
Power source type ATX
Audio chip Realtek ALC4080
Product colour White
Storage controllers
RAID levels 0, 1, 5, 10
Number of HDDs supported 2
Supported storage drive types HDD & SSD
Supported storage drive interfaces M.2, SATA III
Number of storage drives supported 6
RAID support Yes
Packaging data
Package width 353 mm
Package depth 273 mm
Package height 68 mm
Package weight 2.04 kg


SKU: 90MB1J50-M0EAY0 Category:
